שיוך מוצר
AX4200 ultimate AX performance: 574+3603 Mbps
WiFi קצב נתונים
802.11a : עד 54 Mbps
WiFi 5 (802.11ac) : up to 2600 Mbps
802.11n (256QAM) : עד 600 Mbps
802.11ax (2.4GHz) : עד 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 3603 Mbps
אנטנה
Internal antenna x 5
מעבד
2.0GHz quad-core 64bit processor
מגבירי מהירות
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
20/40/80/160 MHz bandwidth
Operating Frequency
2.4G Hz / 5 GHz
מצב הפעלה
Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge
כניסות/יציאות
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 3
USB 3.2 Gen 1 x 1, USB 2.0 x 1
לחצנים
WPS Button, Reset Button, Power Switch
Power & Status Combo LED x 1
הספק חשמל
AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 2.5 A current
ממדי מוצר
131 x 37.5 x 200 mm (WxDxH)
Safe Browsing
• Maximum Parental Control Profile : 64
• Maximum Parental Control Content Filter Rule : 64
• Maximum Guest Network Rule : 2.4 GHz x 3, 5 GHz x 3
Guest Network Connection Time Limit
Guest Network Encryption : Open system, WPA/WPA2/WPA3-Personal, WPS
WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support
כן
Security Scan
• Maximum Firewall Keyword Filter : 64
• Maximum Firewall Network Service Filter : 32
• Maximum Firewall URL Filter : 64
-- Maximum Bandwidth Limiter Rule : 32
Traditional QoS-
-- Maximum Traditional QoS Rule : 32
• Traffic Analysis Period : Daily, Weekly, Monthly
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
• Maximum Port Forwarding Rule : 64
• Maximum Port Triggering Rule : 32
NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Passthrough, PPPoE relay
• Maximum Manually Assign IP Address Rule : 64
• Maximum MAC Filters : 64
File System : HFS+, NTFS, vFAT, ext2, ext3, ext4
New Device Connect Notification
