Boost Speed -
Memory Speed 28
Memory Bandwidth (GB/s)
672
Outputs DisplayPort 2.1b with UHBR20
(x3), HDMI 2.1b
Multi-Screen 4
Resolution 4K at 480Hz or 8K at 165Hz with DSC
Power Input
1x16 (1x16 to 2x8 adapter included)
Bus Type
PCI-Express 5.0 x16
Card Dimensions
11.80” x 4.73” x1.9”; 2.4 Slot
299.5 x 120.0 x 48.0mm; 2.4 Slot
Box Dimensions
15.04” x 7.64” x 2.84”
SYSTEM REQUIREMENTS
PCI Express Gen 5 compliant motherboard with one 2.4-width x16
graphics slot Two connectors 650 W supply² Windows 11 64-bit, Windows 10.64- bit, Linux 64-bit Internet connection'
8-pin supplementary power or greater system power
